3T EXPLORO LTD Rahmenset PostMount
Lieferumfang:
LTD Rahmen
LTD Gabel
Sattelstütze
Steuersatz
Steckachsen
Gewicht Rahmen ca. 950g
Auf Wunsch bauen wir das Rad auch komplett für Sie auf - Bei Interesse kontaktieren Sie uns einfach kurz!
Technische Details:
FORK/GABEL: 3T Luteus II LTD 15mm thru axle (included)
BB / Tretlagerstandard: BB386EVO
Chainring Fit:
Max inner ring: 36T Max outer ring: 50T Max single ring (offset ring): 46T Max single ring (flat ring): 50TThe above applies to round rings, oval rings come in various shapes and need to be measured individually.
Headset / Steuersatz: Integrated tapered IS42/28.6 | IS52/40
Seatpost / Sattelstütze: 3T Charlie Sqaero
Rear Axle / hintere Achse: 142x12mm thru axle (Syntace X-12)
Rear Brake Standard: Post mount for 160mm disc
Cable Routing: internal via interchangeable FlipTop covers for 1x10/11, 2x10/11, Di2, etap
3T STRADA Due Team Rahmenset
--> Passt für alle Schaltgruppen - auch mit Umwerfer vorn! 2x11 und 1x11
--> nur für elektronische Gruppen wenn ein Umwerfer montiert wird - bei 1x11 Gruppen auch mechanisch!
Frame material
Unidirectional carbon
Frame weight (+/-3%)
1005g (Medium, frame-only)
Fork weight (+/-3%)
395g
Fork
Fundi TEAM flat mount disk brake for 12mm thru axle
BB
BB386EVO
Headset
1 1/4" - 1 1/8" Integrated tapered IS42/28.6 | 47/33
Seatpost
3T Charlie Sqaero Strada (CHARLIE EXPLORO is NOT compatible with the STRADA frame)
Thru-axles
3T custom length Syntace X-12: 142x12mm rear, 100x12mm front
Front brake
Flatmount integrated for 140 & 160mm disc
Rear brake
Flatmount for 140 or 160mm disc
Cable routing
Internal via interchangeable FlipTop covers for 2x Di2, eTap and EPS
Tire clearance
Effective width: 30mm, Wheel radius: 344mm. More info
Finish
Gray with black logos
Included in box
Frame, fork, headset, seatpost, seatpost internal clamp, front and rear thru axle, 2 rear derailleur hangers, noise-cancelling foam sleeve to cover shifter cables and brake hose.
3T STRADA Due Team Rahmenset, Farbe tesm stealth
--> Passt für alle Schaltgruppen - auch mit Umwerfer vorn! 2x und 1x
--> nur für elektronische Gruppen wenn ein Umwerfer montiert wird
--> bei 1x11/12 Gruppen auch mechanische Schaltung möglich!
Frame material
Unidirectional carbon
Frame weight (+/-3%)
1005g (Medium, frame-only)
Fork weight (+/-3%)
395g
Fork
Fundi TEAM flat mount disk brake for 12mm thru axle
BB
BB386EVO
Headset
1 1/4" - 1 1/8" Integrated tapered IS42/28.6 | 47/33
Seatpost
3T Charlie Sqaero Strada (CHARLIE EXPLORO is NOT compatible with the STRADA frame)
Thru-axles
3T custom length Syntace X-12: 142x12mm rear, 100x12mm front
Front brake
Flatmount integrated for 140 & 160mm disc
Rear brake
Flatmount for 140 or 160mm disc
Cable routing
Internal via interchangeable FlipTop covers for 2x Di2, eTap and EPS
Tire clearance
Effective width: 30mm, Wheel radius: 344mm. More info
Finish
Stealth
Included in box
Frame, fork, headset, seatpost, seatpost internal clamp, front and rear thru axle, 2 rear derailleur hangers, noise-cancelling foam sleeve to cover shifter cables and brake hose.
3T STRADA Team Rahmenset
nur für 1x11 Schaltgruppen (kein Umwerfer vorne möglich!)
Frame material
Unidirectional carbon
Frame weight (+/-3%)
970g (Medium, frame-only)
Fork weight (+/-3%)
395g
Fork
Fundi TEAM flat mount disk brake for 12mm thru axle
BB
BB386EVO
Headset
1 1/4 - 1 1/8 Integrated tapered IS42/28.6 | 47/33
Seatpost
3T Charlie Sqaero Strada (CHARLIE EXPLORO is NOT compatible with the STRADA frame)
Thru-axles
3T custom length Syntace X-12: 142x12mm rear, 100x12mm front
Front brake
Flatmount integrated for 140 & 160mm disc
Rear brake
Flatmount for 140 & 160mm disc
Cable routing
Internal via interchangeable FlipTop covers for 1x mechanical, Di2
Tire clearance
Effective width: 30mm, Wheel radius: 344mm. More info
Finish
Stealth black or red with white logos. Ready-to-paint frames also available
Included in box
Frame, fork, headset, seatpost, seatpost internal clamp, front and rear thru axle, 2 rear derailleur hangers, noise-cancelling foam sleeve for rear derailleur housing and brake hose
Argon 18 Nitrogen PRO Rahmenset 2018 (Felgenbremse / Rimbrake)
Lieferumfang:
Argon 18 Nitrogen PRO Rahmen (Carbon) Nanotech Tubing HM8003
Argon 18 Nitrogen PRO Gabel (Carbon)
Argon 18 Nitrogen PRO Sattelstütze ASP 5100 (Carbon)
Argon 18 AHB-5000 Rennradlenker- mit Vorbaueinheit (Carbon, flexible Vorbaulängen)
3D Steuersatz inkl. 0mm, 15mm und 25mm 3D Steuersatz kappe zur Anpassung der Steuerrohrhöhe (Erhöhung des Stack-Wertes möglich!
Bremsensatz (vorn und hinten)
Schneller zu sein, muss nicht immer bedeuten, mehr Watt auf die Pedale zu bringen: Mit der timemachine TMR bist du schneller bei gleichbleibendem Poweroutput. Der Entscheid von BMC, ein aerodynamisches Strassenrad zu entwickeln war an die Bedingung geknüpft, nicht nur von Aerodynamik zu sprechen, sondern diese umzusetzen. Die timemachine TMR kombiniert maximale Aerodynamik, Integration und Steifigkeit und entwickelte sich rasch zum Liebling der Rouleure und Sprinter des BMC Racing Teams. Aber auch Triathleten, bei deren Wettkämpfen das Windschattenfahren erlaubt ist, haben das TMR als entscheidenden Vorteil entdeckt.
LIEFERUMFANG
BMC TimeMachine Road Rahmen
BMC TimeMachine Road Gabel
Steuersatz
BMC TimeMachine Road Sattelstütze 30 / 15 / 0 Offset
vordere und hintere Bremse inkl. Carbin Abdeckungen für vorn
Technische Details
Rahmen: p2p x subA Technologie; 01 Premium Carbonfaser
Tretlagerstandard: BB86 PressFit
Gabel: aero road fork, pure carbon, with subA
Größe: nur noch 58cm
Bremsen: integrated road design Felgenbremse
Sattlestütze: aero road post, pure carbon, with p2p & subA; verschiedene Positionen 30 / 15 / 0 mm Offset
Farbe: CMKY (2015)
Dieses Modell wurde technisch identisch von 2013 bis 2018 gebaut mit Felgenbremse
Schneller zu sein, muss nicht immer bedeuten, mehr Watt auf die Pedale zu bringen: Mit der timemachine TMR bist du schneller bei gleichbleibendem Poweroutput. Der Entscheid von BMC, ein aerodynamisches Strassenrad zu entwickeln war an die Bedingung geknüpft, nicht nur von Aerodynamik zu sprechen, sondern diese umzusetzen. Die timemachine TMR kombiniert maximale Aerodynamik, Integration und Steifigkeit und entwickelte sich rasch zum Liebling der Rouleure und Sprinter des BMC Racing Teams. Aber auch Triathleten, bei deren Wettkämpfen das Windschattenfahren erlaubt ist, haben das TMR als entscheidenden Vorteil entdeckt.
LIEFERUMFANG
BMC TimeMachine Road Rahmen (nur für Felgenbremse)
BMC TimeMachine Road Gabel (nur für Felgenbremse)
Steuersatz
BMC TimeMachine Road Sattelstütze 30 / 15 / 0 Offset
vordere und hintere Bremse inkl. Carbon-Abdeckung für vorn
Technische Details
Rahmen: p2p x subA Technologie; 01 Premium Carbonfaser
Tretlagerstandard: BB86 PressFit
Gabel: aero road fork, pure carbon, with subA
Größe: nur noch 58cm
Bremsen: integrated road design Felgenbremse
Sattlestütze: aero road post, pure carbon, with p2p & subA; verschiedene Positionen 30 / 15 / 0 mm Offset
Farbe: Team Red / carbon-rot-weiss (2015)
Dieses Modell wurde technisch identisch von 2013 bis 2018 gebaut mit Felgenbremse
BMC GF01 DISC GranFondo 01 / white / 48cm
Dieses Rahmenset beinhaltet:
Rahmen
Gabel
Steuersatz
Rahmen: TCC, with angle compliance
Rohrmaterial: Pure Carbon
Größe: 48 cm
Gabel: compliancefork, pure carbon, w TCC
Farbe:white
Post Mount Aufnahmen für die Bremssättel
BMC TimeMachine 01 DISC Rahmenset (Triathlon) inkl. Flat-Cockpit
The Timemachine 01 Disc is the latest evolution of our all-conquering, drag-defying race machine. Its highly sophisticated aerodynamics, adjustability and component integration ensure you can perform at your best. The Vmax Aero Design Premium Carbon frame includes aero disc caliper covers, sliding dropouts, rear storage, a dual position aero seatpost and our Flat Cockpit with Profile Design T4+ Carbon extensions. Now you have the foundation for your fastest ride yet, the rest of your dream bike’s build is up to you.
RAHMEN /Frame
Timemachine 01 Disc Premium Carbon with Vmax Aero Design and P2P Positioning SyStem
Internal Di2 Battery Mount
PF86 Bottom Bracket
Rear Storage Box
Aero Caliper Cover
Sliding Dropouts
Flat Mount Disc
12x142mm Thru-Axle
GABEL / Fork
Timemachine 01 Disc Premium Carbon with Vmax Aero Design Hinge Design
Aero Caliper Cover
Flat Mount Disc
12x100mm Thru-Axle
LENKEREINHEIT / Handlebar BMC Flat Cockpit / Profile T4+ Carbon Extensions
SATTELSTÜTZE / Seatpost Timemachine 01 Premium Carbon V-Max Aero Seatpost, 62mm Offset Adjustment, P2P Dual-Mount Aeropost Configuration (Triathlon & Time Trial)
REIFENFREIHEIT / Tire Clearance 27mm (Measured Width)
GEWICHTSLIMIT / Weight Limit 110 Kg
BMC TimeMachine 01 DISC Rahmenset (Triathlon) inkl. Flat-Cockpit
The Timemachine 01 Disc is the latest evolution of our all-conquering, drag-defying race machine. Its highly sophisticated aerodynamics, adjustability and component integration ensure you can perform at your best. The Vmax Aero Design Premium Carbon frame includes aero disc caliper covers, sliding dropouts, rear storage, a dual position aero seatpost and our Flat Cockpit with Profile Design T4+ Carbon extensions. Now you have the foundation for your fastest ride yet, the rest of your dream bike’s build is up to you.
RAHMEN /Frame
Timemachine 01 Disc Premium Carbon with Vmax Aero Design and P2P Positioning SyStem
Internal Di2 Battery Mount
PF86 Bottom Bracket
Rear Storage Box
Aero Caliper Cover
Sliding Dropouts
Flat Mount Disc
12x142mm Thru-Axle
GABEL / Fork
Timemachine 01 Disc Premium Carbon with Vmax Aero Design Hinge Design
Aero Caliper Cover
Flat Mount Disc
12x100mm Thru-Axle
LENKEREINHEIT / Handlebar BMC Flat Cockpit / Profile T4+ Carbon Extensions
SATTELSTÜTZE / Seatpost Timemachine 01 Premium Carbon V-Max Aero Seatpost, 62mm Offset Adjustment, P2P Dual-Mount Aeropost Configuration (Triathlon & Time Trial)
REIFENFREIHEIT / Tire Clearance 27mm (Measured Width)
GEWICHTSLIMIT / Weight Limit 110 Kg
BMC Timemachine ROAD 01 Module Rahmenset / tmr01
Rahmen Timemachine Road 01, PF86 bottom bracket, Flat Mount, 12x142mm thru-axle
RohrsatzAerodynamic 01 Premium Carbon
Grössen 51 / 54 / 56 / 58 / 61
GabelTimemachine Road 01 Aerodynamic Premium Carbon Disc, TCC Speed, Flat Mount w/ Caliper Cover, 12x100mm thru-axle
Lenker BMC ICS Aero, aero top shape, compact bend
Vorbau BMC ICS Aero- Integrated Aero Cockpit Design, w/ computer mount
SattelstützeBMC Aero post, 01 premium carbon, p2p
FarbeStealth
Schweizer Ingenieurskunst
Dieser kompromisslose Racer stillt deinen Hunger nach Geschwindigkeit – durch Qualität und Präzision. Die Timemachine Road ist das Ergebnis einer umfassenden Aero-Bauweise, verfeinert durch exakte CFD Simulationen sowie durch Tests im Windkanal und in der Praxis.
Ultimative Integration
Integration ist das Herz der Innovationen: Jede Komponente der Timemachine Road wurde in ein super cleanes System-Design integriert. Das Ziel? Maximale Geschwindigkeit. Das neue ICS Aero Cockpit hat nur eine minimale Stirnfläche und verfügt über ein integriertes Zugführungssystem. Das reduziert den Luftwiderstand ohne Einbußen in Sachen Funktionalität oder Passform.
Kraftübertragung
Die Timemachine Road steht für maximale Effizienz: Sie schenkt dank seiner außergewöhnlichen Tretlager- und Kettenstrebensteifigkeit selbst dem stärksten Fahrer ein Extra an Speed – besonders bei radikalen Sprints oder schnellen Antritten.
Geschwindigkeit + Komfort
Komfort und Geschwindigkeit sind das perfekte Team: Unsere speziell entwickelte TCC Speed Technology absorbiert die Vibrationen der Straße und sorgt so für ein ebenso geschmeidiges wie effizientes Fahrgefühl.
